MikroTik Traffic Classification Using Mangle (LocalToGlobal, GlobalToLocal, LocalToLocal)
MikroTik Traffic Classification Using Mangle (LocalToGlobal, GlobalToLocal, LocalToLocal)
This guide explains how to classify network traffic in RouterOS running on MikroTik routers using Firewall Mangle. The goal is to divide traffic into five logical directions:
  • LocalToGlobal – client traffic going to the Internet
  • GlobalToLocal – Internet traffic coming to clients
  • LocalToLocal – traffic between subscribers in the same network
  • LocalToMikrotik – traffic from subscribers to the router
  • MikrotikToLocal – traffic generated by the router to clients
This traffic model is very useful for Internet Service Providers and large local networks because it allows:
  • bandwidth shaping using Queue Tree and PCQ
  • blocking client-to-client traffic
  • prioritizing management or service traffic
  • monitoring router-generated traffic

1. Network Concept

The following diagram represents the logical traffic directions:
Client → Internet      LocalToGlobal
Internet → Client      GlobalToLocal
Client → Client        LocalToLocal
Client → Router        LocalToMikrotik
Router → Client        MikrotikToLocal
To implement this architecture we will use two steps:
  1. Mark connections
  2. Mark packets based on those connections

2. Creating an Address List for Local Networks

First create an address list that contains all subscriber networks. This list will be used to detect internal traffic.
/ip firewall address-list

add list=Local address=10.0.0.0/8
add list=Local address=172.16.0.0/12
add list=Local address=192.168.0.0/16
If your network uses a different addressing scheme, replace these ranges with your actual subscriber networks.

3. Marking Connections

Connection marking is the first step. Each new connection will be assigned a specific direction label.

LocalToGlobal (Client → Internet)

/ip firewall mangle
add chain=prerouting \
src-address-list=Local \
dst-address-list=!Local \
connection-mark=no-mark \
action=mark-connection \
new-connection-mark=LocalToGlobal_conn \
passthrough=yes

GlobalToLocal (Internet → Client)

add chain=prerouting \
src-address-list=!Local \
dst-address-list=Local \
connection-mark=no-mark \
action=mark-connection \
new-connection-mark=GlobalToLocal_conn \
passthrough=yes

LocalToLocal (Client → Client)

add chain=prerouting \
src-address-list=Local \
dst-address-list=Local \
connection-mark=no-mark \
action=mark-connection \
new-connection-mark=LocalToLocal_conn \
passthrough=yes

LocalToMikrotik (Client → Router)

add chain=input \
src-address-list=Local \
connection-mark=no-mark \
action=mark-connection \
new-connection-mark=LocalToMikrotik_conn \
passthrough=yes

MikrotikToLocal (Router → Client)

add chain=output \
dst-address-list=Local \
connection-mark=no-mark \
action=mark-connection \
new-connection-mark=MikrotikToLocal_conn \
passthrough=yes

4. Marking Packets

Once connections are marked, we classify packets belonging to those connections. These packet marks are later used for traffic shaping and filtering.

Internet Upload Traffic

add chain=forward \
connection-mark=LocalToGlobal_conn \
action=mark-packet \
new-packet-mark=LocalToGlobal_pkt \
passthrough=no

Internet Download Traffic

add chain=forward \
connection-mark=GlobalToLocal_conn \
action=mark-packet \
new-packet-mark=GlobalToLocal_pkt \
passthrough=no

Local Network Traffic

add chain=forward \
connection-mark=LocalToLocal_conn \
action=mark-packet \
new-packet-mark=LocalToLocal_pkt \
passthrough=no

Traffic to Router

add chain=input \
connection-mark=LocalToMikrotik_conn \
action=mark-packet \
new-packet-mark=LocalToMikrotik_pkt \
passthrough=no

Router Generated Traffic

add chain=output \
connection-mark=MikrotikToLocal_conn \
action=mark-packet \
new-packet-mark=MikrotikToLocal_pkt \
passthrough=no

5. Practical Use Cases

Bandwidth Limiting

The marks LocalToGlobal_pkt and GlobalToLocal_pkt can be used with Queue Tree to limit upload and download speeds per subscriber.

Blocking Client-to-Client Traffic

/ip firewall filter
add chain=forward connection-mark=LocalToLocal_conn action=drop
This prevents subscribers from accessing devices of other subscribers.

Allowing Router Access

Even when LocalToLocal traffic is blocked, clients can still reach the router using the LocalToMikrotik direction for services like:
  • DNS
  • DHCP
  • WinBox
  • API
  • Monitoring

6. Important Notes

  • Disable FastTrack if Queue Tree shaping is used.
  • Ensure address lists correctly represent your network.
  • Keep connection marking rules above packet marking rules.
  • Test rules using /ip firewall mangle print stats.

Conclusion

This five-direction traffic classification model provides a flexible and powerful framework for managing large subscriber networks on MikroTik routers. By clearly separating Internet traffic, local traffic, and router traffic, network administrators gain precise control over bandwidth usage, security, and service prioritization.
